Es Panel Fan Mechanical ventilation

Es Panel Fan
fond titre  produit

Es Panel Fan

No electrician required / on 115v only

The ES panel fan consists of an agriculture grade, variable speed motor attached
to an aluminum shutter with tie bar to eliminate shutter flapping and locking open.
The motor is connected to the shutter with a heavy duty chrome plated OSHA
approved guard.
The fan is totally assembled at our factory so you just pull it out of the box and plug it in.

Maxum exhaust fans, when applied properly, can be used in the following applications:

  • Removes and controls unwanted condensation
  • Eliminates heat build–up inside your buildings
  • Designed for agriculture, horticulture and industrial applications
  • Air Exchange
  • Improves air quality

When installing any Maxum exhaust fan, you must provide a proper inlet
Give us a call to help you with a Maxum approved inlet or control to go
with your high performance exhaust fan. A properly designed Maxum
ventilation system will give you exceptional results.

External hoods available

External hoods available

Features :

  • Unbelievable smooth and quiet operation
  • Comes totally assembled out of the box
  • No electrician required when plugged into a locally approved electrical circuit
  • Aluminum blade with a zinc plated steel hub balanced for smooth vibration–free operation. Pitch is designed to correlate with motor horsepower to
    deliver maximum efficiency.
  • Chrome grill allows for easy cleaning and meets OSHA guidelines. (OSHA approved on interior wall and approved on exterior wall when mounted 7’ (2.14 m)
    above ground.)
  • 10’ (3.05 m) cord attached is wired for 115 Volt plug
    v High efficiency aluminum shutters with tie bar to eliminate shutter flapping and opening on windy days
  • Extremely energy efficient, totally enclosed maintenance free, direct drive high efficiency motors have completely sealed ball bearings, UL and ULC certification, built in automatic thermal overload protection, covered by a Full One Year Warranty
